Codent HEM1 電動馬達組

詳細影片介紹

Specifications and Features 產品規格與特色:

This product is a complete electric motor device.

It adopts a precision electric motor as the main power source

and equipped with high-brightness LED as the light source.

It has the following features: Free maintenance, micro vibration and

low noise, easy to operate.

Achieve electric control and pneumatic control of the motor by

connecting the power supplying the water and air.

本產品是完整性的電動馬達控制設備，採用精密的電動馬達做為主要動力來源，

配備高亮度LED 做為光源，本產品具有下列特點 : 免定期維修， 微震動及低

噪音，操作簡易，使用方便。只需接通電源，連接水氣就能達成對馬達的電動控

制和氣動控制。

1. Brush-Less Electric Motor 電動馬達單體

Max Speed: 40000±2% (RPM) 最高轉速: 40000±2% (RPM)
Min Speed: 2000±2% (RPM) 最低轉速: 2000±2% (RPM)
Max Torque: 3 .5 Ncm 最大扭力: 3 .5 Ncm
Size: ∅22×L72 mm 尺寸: ∅22×L72 mm
Weight: 68 g 重量: 68 g
Light: White LED 光源: White LED

2. Control Unit 控制盒430g，約手掌大小

Digital Speed Display數位螢幕顯示
3 Memory Modes 3種記憶模式
5 Handpiece Ratio Modes 5種手機轉速模式
Forward / Reverse Switchable 正 / 反轉切換功能
Light Brightness Adjustment Function 亮度調節功能
Pneumatic氣壓/線性調整功能

3. 12 Months Product Warranty 正常使用保固12個月

4. Design, Manufacture, And Quality Assurance In Taiwan 台灣研發設計，製造，品管
